Why You'll Love It
- 3 devices in 1: smart dimmer, motion sensor, and lux sensor
- Automatic lighting based on occupancy and ambient light
- 800 series Z-Wave with Z-Wave Long Range support*
- Scene Control with multi-tap, hold, and release actions*
- Smart Bulb Mode for Philips Hue and other smart bulbs*
- Smooth LED dimming up to 150 Watts
- Direct 3-way installation with a standard mechanical switch (or virtual 3-way with 2 Zooz switches)
- Highly customizable through advanced Z-Wave settings*
- SmartStart pairing and S2 security
- Designed and supported by Zooz with US-based technical support and a 5-year extended warranty when registered within 30 days of purchase
NOTE: Z-Wave hub required - sold separately. *Your smart hub / controller needs to support advanced settings for you to take advantage of this feature.
Three Smart Devices in One
Stop buying separate sensors.
The Motion Dimmer combines:
- Smart Z-Wave dimmer
- Motion sensor
- Lux (ambient light) sensor
The built-in motion sensor detects movement up to 25 feet away, while the integrated lux sensor continuously monitors ambient brightness. Together, they allow your lights to react only when someone is present and when additional lighting is actually needed.
Instead of creating automations using multiple devices, everything happens directly from the wall switch for a cleaner installation and a more reliable smart home.
Separate DevicesZooz Motion DimmerSmart dimmer✓Motion sensor✓ Built inLux sensor✓ Built inThree devices to installOne deviceMultiple batteries to replaceNoneSeparate automationsEverything in one switch
Automatic Lighting That Works Your Way
By default, the Motion Dimmer turns lights on when motion is detected and switches them off after 30 seconds of inactivity. But that's only the beginning.
Customize:
- Motion sensitivity
- Auto-off delay
- Night mode brightness
- Lux threshold
- Motion reporting
- Lux reporting
- LED indicator color and brightness
Create bright daytime lighting, gentle nighttime illumination, or automation rules tailored to every room in your home.
Smooth, Reliable Dimming
Designed specifically for lighting loads, the Motion Dimmer delivers smooth dimming performance for:
- LED fixtures up to 150 W
- Incandescent lighting up to 500 W
Additional features include:
- Adjustable dimming speed (ramp rate)
- Restore previous brightness after power outages
- Last brightness memory
- Manual dimming from the wall
For lighting only. Do not use with receptacles, motors, fans, fluorescent fixtures, or transformer-powered loads.
Perfect For
The Motion Dimmer is ideal for spaces where hands-free lighting adds comfort, convenience, and energy savings.
Recommended applications include:
- Bathrooms
- Hallways
- Laundry rooms
- Closets
- Pantries
- Mudrooms
- Garages
- Basements
- Utility rooms
- Stairways
SPECIFICATIONS
- Model Number: ZEN12 800LR
- Z-Wave Region: US/MX/CA
- Z-Wave Chip: 800 series with SmartStart, S2 security, and Z-Wave Long Range support
- Power: 120-277V AC, 50/60 Hz
- Maximum Loads:150 W dimmable LED (no electrical dimming for smart bulbs!)500 W Incandescent Do NOT connect to motors, tube lights, receptacles, or fans
- Neutral wire required
- Z-Wave Range: Up to 500 feet line of sight between the hub and the closest Z-Wave receiver module, up to 1300 feet with Z-Wave Long Range enabled (your Z-Wave hub needs to support that feature)
- Motion Sensor Detection: up to 25 ft
- Dimensions: 1.3" deep, 1.75" wide, 4.1" tall with plate (2.72" tall in the back)
- Operating Temperature: 32-104° F (0-40° C)
- Installation: Indoor use only
RESOURCES
Zooz Motion Dimmer ZEN12 800LR Product Manual
Zooz Motion Dimmer ZEN12 800LR Frequently Asked Questions
Advanced Settings
Support Portal
WORKS WITH
- Z-Box Hub (recommended for all Zooz products)
- Home Assistant (Z-Wave JS)
- HomeSeer (Z-Wave Plus or Z-Wave JS Front End)
- Hubitat (integrated)
- SmartThings Hub with custom driver
NOTE: If you don't see your Z-Wave controller on the list above, please contact us before you purchase this product.
